Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability

  • Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability
  • Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability
  • Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability
  • Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability
  • Dongfeng 8 Tons Tilt Tray Flat Bed Tow Trucks Customizable High Durability
Place of Origin Hubei, China
Brand Name Dongfeng
Document Product Brochure PDF
Minimum Order Quantity 1
Packaging Details Nude
Delivery Time 15 days
Supply Ability 30 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Flatbed Wrecker Truck Dimensions (L X W X H) (mm) 10300x2550x2800mm
Condition New Main Winch 8-10 Tons
Underlift 3 Sections, 8-10 Tons Underlift Tow Rating 16-20 Tons
Operation Both Sides Manual Remote Control Optional
Warranty 1 Year Bed Dimension 8000x2500mm
Highlight

Flat Bed Tow Trucks Customizable

,

8 Tons Flat Bed Tow Trucks

,

flatbed towing truck High Durability
Leave a Message
Product Description
4X2 EURO 6 DONGFENG 8 TONS TILT TRAY FLAT BED TOW TRUCKS
Product Description

The 8-10 tons flatbed wrecker truck is available in steel, with multiple deck length and width configurations and different structural deck capacity for more strength and durability on the job.



The truck brand options also available with ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, IVECO, etc.

With Euro 2, Euro 3, Euro 5, Euro 6 emission.

With RHD, LHD.

With 4x2, 4x4.

Other special requirements you want.


Main Features
1. Bed Length around 8 m. Capacity 8-10 Tons.
2. Optional Hitch Ball. Optional Remote Control.
3. Optional Material from Q235B, Q345, G70, NM500, Hardox 450 etc.

Truck Specs
Dongfeng 8-10 Tons Flatbed Wrecker Truck
Overview
Name 8-10 Tons Flatbed Wrecker Truck
Dimension(LxWxH) 10300x2550x2830(mm)
Total Mass 16420Kg
Rated Payload 8000Kg
Kerb Weight 8420Kg
Passenger 3
Approach/Departure Angle 17/8
The Parameters of Chassis
Manufacture/Model Dongfeng
Driving Type 4*2 LHD
Wheel Base 5200 mm
Gearbox Eight speed forward and one reverse, manual
Tyre 10.00R20
The Number of Tyre 6+1(spare tyre)
Front/Rear Suspension 1430/3050(mm)
The Paremeters of Engine
Manufacturer/Model Cummins/ISF4.5
Rated Power 210hp/157kw
Fuel Type Diesel
Displacement/Capacity 4500ml
Emission Standard Euro 6
Cylinder Straight/6/turbo/intercooling
Max. torque 760N.m
Velocity 2500rpm

Body Specs
8 - 10 Tons Slide Type Tilt Tray
General Settings Color

Customizable, electrophoresis

painting is optional
  Winch Capacity 8 - 10 tons
  Lift Capacity 8 - 10 tons
  Extension Capacity 8 - 10 tons
  Underlift Capacity 8 tons (towing up to 16 tons)
  Platform Material Q235B, 6 -8 mm thick
  Platform Type Smooth or checkered
  Platform Dimension 8000-9000 x 2500 mm
  Wireless Remote Control Equipped
  Subframe with Underlift Equipped and match to chassis
Lights Siren Long Lamp with Speaker 1 pcs
  Sides Lights 10 pcs
  Frame Lights with Lights Seat 8 pcs
Hydraulic System Bed Extension Cylinder with Seat 1 pcs
  Bed Lift Cylinder with Seat 2 pcs
  Supporting Legs Cylinder 2 pcs
  Hydraulic Winch 1 pcs
  Hydraulic Pump 1 pcs
  Hydraulic Multi Way Valve 1 pcs
  Hydraulic Balance Valve 2 pcs (1 for lift and 1 for underlift)
  Hydraulic Hose 1 set
  Hydraulic Hose Containment 1 set
  Hose Sleeve 1 pcs
  Manual Control with Stainless Steel Seat 2 sets (on both sides)
  Oil Tank 1 pcs
Accessories Wheel Trolleys 2 pcs
  Straps 4 pcs
  Toolbox 2 pcs
  Wheel Grids 2 pcs
  L arms 2 pcs
  Fence 2 pcs
  Mudflap 2 pcs
  Lamp Frame 1 pcs
  Bed Position Limit 1 set
  Frame and Lights Bolts 1 set
  Toolbox and Fence Brackets Square Tube 1 set
  Container Pins 4 pcs
