Dongfeng Double Deck Carrier Tilt And Slide Recovery Trucks 4x2 Euro 3
| Place of Origin | Hubei, China |
|---|---|
| Brand Name | Dongfeng |
| Document | Product Brochure PDF |
| Minimum Order Quantity | 1 |
| Packaging Details | Nude |
| Delivery Time | 15 days |
| Supply Ability | 30 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Flatbed Wrecker Truck | Dimensions (L X W X H) (mm) | 9500x2550x2800mm |
|---|---|---|---|
| Condition | New | Main Winch | 4 Tons |
| Underlift | 3 Sections, 5 Tons | Underlift Tow Rating | 10 Tons |
| Operation | Both Sides Manual | Remote Control | Optional |
| Warranty | 1 Year | Bed Dimension | 7000x2500mm |
| Highlight | Dongfeng Tilt And Slide Recovery Trucks,Tilt And Slide Recovery Trucks 4x2,Double Deck tilt slide tow truck |
||
Product Description
| 6 Tons Double Deck Wrecker Body | ||
| General Settings | Color |
Customizable, electrophoresis painting is optional |
| Winch Capacity | 4 tons | |
| First Deck Lift Capacity | 6 tons | |
| Second Deck Lift Capacity | 3 tons | |
| Extension Capacity | 6 tons | |
| Underlift Capacity | 5 tons (tow up to 10 tons) | |
| Platform Material | Q235R, 3/4mm thick | |
| Platform Type | Checkered | |
| Platform Dimension |
Around 7200 x 2400 mm for first deck, 4600 x 2200 mm for second deck |
|
| Wireless Remote Control | Optional, extra USD500 | |
| Subframe with Underlift | Match to chassis | |
| Lights | Siren Long Lamp with Speaker | 1 pcs |
| Sides Lights | 8 pcs | |
| Frame Lights with Lights Seat | 6 pcs | |
| Hydraulic System | Bed Extension Cylinder with Seat | 1 pcs |
| Bed Lift Cylinder with Seat | 2 + 2 pcs | |
| Underlift lift Cylinder | 2 pcs | |
| Underlift Extension Cylinder | 1 pcs | |
| Hydraulic Winch | 1 pcs | |
| Hydraulic Pump | 1 pcs | |
| Hydraulic Multi Way Valve | 1 pcs | |
| Hydraulic Balance Valve | 3 pcs (2 for lifts and 1 for underlift) | |
| Hydraulic Hose | 1 set | |
| Hydraulic Hose Containment | 1 set | |
| Hose Sleeve | 1 pcs | |
| Manual Control with Stainless Steel Seat | 2 sets (on both sides) | |
| Oil Tank | 1 pcs | |
| Accessories | Wheel Dollies | 2 pcs |
| Straps | 4 pcs | |
| Toolbox | 2 pcs | |
| Wheel Grids | 2 pcs | |
| L arms | 2 pcs | |
| Fence | 2 pcs | |
| Mudflap | 2 pcs | |
| Lamp Frame | 1 pcs | |
| Bed Position Limit | 1 set | |
| Frame and Lights Bolts | 1 set | |
| Tool Box and Fence Brackets Square Tube | 1 set | |
